Artillery insignia   Artillery   Artillery insignia




Artillery Half-section at Ft. Sill
Photo: Ft. Sill PIO
This is a typical WW-I and Post WW-I
deployment of a 75mm Howitzer



 INDEX



 Two excellent artillery stories!

Magazine reprints with permission from
 "America's Civil War" magazine



Introduction
"The primary force of the US Army consists of the Combat Arms.  The Combat Arms are comprised of the Field Artillery Branch, the Infantry Branch, and the Armor Branch.  Of these three, the Field Artillery is known as the "King of Battle".  In the history of modern warfare it has always been the artillery that decided final victory on the battlefield.  At the conclusion of WW II, General George S. Patton stated his army "could not have been as successful as it was without the Field Artillery."

Artillery insignia


Branch Insignia:
Two crossed field guns, gold color metal, 13/16 inch in height.

Crossed cannons (field guns) for Artillery have been in continuous use since 1834, when they were placed on regimental colors, knapsacks, and as part of the cap insignia for Artillery officers. In 1901, the Artillery was divided into Coast and Field Artillery and the branch insignia was modified by the addition of a plain scarlet oval at the intersection of the cannons. The Field Artillery insignia, approved on 17 July 1902, had a gold wheel on the red oval, and the Coast Artillery had a gold projectile on the red oval.

Coast artillery insignia

Coast Artillery Insignia

This red oval and wheel was replaced on 4 April 1907 by two field guns. It was superseded in 1957 by the consolidated Artillery insignia consisting of the crossed field guns surmounted by a missile. In 1968 when the Air Defense Artillery and the Field Artillery were authorized to have separate insignia, the former Field Artillery insignia was reinstated.

Artillery plaque

Branch Plaque

Branch Plaque:
The plaque design has the branch insignia, letters and border in gold. The background is scarlet.

Regimental Insignia:
Personnel assigned to the Field Artillery branch affiliate with a specific regiment and wear the insignia of the affiliated regiment.

Regimental Coat of Arms:
There is no standard Field Artillery regimental flag to represent all of the Field Artillery regiments. Each regiment of Field Artillery has its own coat of arms that appears on the breast of a displayed eagle. The background of all the Field Artillery regimental flags is scarlet with yellow fringe.

Branch Colors:
Scarlet - 65006 cloth; 67111 yarn; 200 PMS.

The uniform for the Corps of Artillery, which was formed in 1777, included red trimmings. The plume on the hat was also red. Except for a short period at the beginning of the 1800's when yellow was combined with it, scarlet has been the color of the Artillery throughout the history of the branch. Scarlet has been used by the Coast Artillery, Air Defense Artillery, and Field Artillery.

Birthday:
17 November 1775. The Continental Congress unanimously elected Henry Knox "Colonel of the Regiment of Artillery" on 17 November 1775. The regiment formally entered service on 1 January 1776. Although Field Artillery and Air Defense Artillery are separate branches, both inherit the traditions of the Artillery branch.

The term "Redlegs":
Artillerymen are often referred to as "redlegs" for two reasons, dating back to the 1800's.  Red appeared on two artillery uniforms, 1) when artillerymen wore uniform trousers with a two-inch red stripe, and 2) when red canvas leggings were worn by horse artillerymen.

Information and image source: The Institute of Heraldry



The following article is reprinted with the permission of:

America's Civil War
Copyright 2001
dba PRIMEDIA Enthusiast Publications

741 Miller Drive, SE, Suite D-2
Leesburg, VA  20175
Subscription # (800) 829-3340
Outside the US (904) 446-6914



A well-drilled artillery battery,
like a choreographed ballet,
had no wasted parts or movements.

By Ross M. Kimmel

Civil War artillery
Coordinating the action and movement of an artillery battery
was an immense responsibility, as suggested by this image,
which shows only half the components of a full-strength
Union battery.  Photo: National Archives

Frederick the Great, the warrior king of Prussia, once said his artillery lent dignity to what otherwise would be a vulgar brawl."  What Frederick realized was that, of the three main combat arms of 18th-century warfare, artillery required far greater knowledge, care and finesse than did infantry or cavalry. The validity of Frederick's observation was recognized in the United States a century later. Graduates of the United States Military Academy at West Point were apportioned to the branches of service based upon their class standings. The top tier went into the engineers, the second into the artillery, the third to the cavalry and the bottom to the infantry.
While engineering was the most sophisticated discipline within the art of warfare and required the most advanced knowledge of mathematics and applied physics, it was essentially a noncombatant arm. Artillery also required an advanced knowledge of mathematics and applied physics, but gunners always had to put their learning to use during the chaos of battle. The artillery branch demanded of its commanders technical knowledge not required of cavalry and infantry commanders, and thus, of the combat arms in the 19th-century U.S. Army, the artillery received the most accomplished West Point graduates.
In practical terms, an artillery commander had greater responsibility than did a commander of cavalry or infantry. An infantry captain had, on paper, to care for about 100 men. He saw to their training, arming, clothing and equipping, feeding and discipline. A cavalry captain also had to watch over about 100 men, but he was also responsible for 100 horses that required equipping, training, feeding and care.
By comparison, an artillery captain in a full six-gun battery had responsibility for about 120 men, 120 horses, six fieldpieces, 12 limbers, six caissons, a traveling forge, a battery wagon and two supply wagons. Four-gun batteries were common in both armies during the Civil War, and an artillery captain may have had the number of men in his command reduced by a third. Even so, the breadth of his responsibility exceeded that of the leaders of full-strength cavalry and infantry companies. Ironically, while artillery required of its commanders the highest level of competence, it also offered the slowest opportunities for advancement, since it was a small branch of service with far fewer senior officers than the infantry.
Before describing the various hardware components of a Civil War artillery battery, it is necessary to understand how one was organized. The commanding captain was assisted by a lieutenant for each section, which consisted of two guns, with their accompanying men, horses, limbers and caissons. The lieutenants were section chiefs. Each gun, with its men, horses and attendant vehicles, operated as a platoon under the command of a sergeant known as the chief of the piece. When in action, each gun, with one limber supplying ammunition, was commanded by a corporal called the gunner, and each gun's caisson with an additional limber was stationed to the rear under command of another corporal. Drivers, who handled the horses, and cannoneers, who manned the guns, were privates.
In addition to the men in line of command, a battery would also have a bugler and a guidon-bearer, as well as a first sergeant who was responsible for the battery's paperwork and during battle was available to do any task assigned by the officers, including assuming command of any gun or section whose chief was incapacitated. Ideally, each battery would have several artificers to work the traveling forge, performing farrier services and minor equipment repair in the field. (Sometimes several batteries together in a battalion would share a forge and artificers.) If a battery was fortunate enough to have a supply wagon or two, there would be additional teamsters and horses or mules. One Confederate battery maintained its own ambulance, at least for part of the war, to evacuate its wounded.
At first during the Civil War, individual batteries were apportioned out to infantry or cavalry brigades for tactical support in the field, with the batteries subject to ultimate command by officers not trained in artillery. First the Army of Northern Virginia, then by war's end most other armies, adopted a battalion system whereby four to six batteries were organized into artillery battalions commanded by majors or lieutenant colonels. Battalions were assigned to support divisions--at least in the infantry--and additionally, major armies maintained separate trains of reserve artillery that could be deployed in battle as the commanding general saw fit.
Artillery assigned to infantry support was called mounted artillery, a misnomer since all the cannoneers marched on foot. Officers, sergeants, guidon-bearers, buglers and drivers were mounted. Artillery assigned to the cavalry was called horse artillery, and everyone of necessity was mounted so that they could keep up with the troopers. That meant that the battery could have more horses than men, further adding to the captain's burden of responsibility.
Federal and Confederate armies were composed overwhelmingly (about 80 percent) of infantry, and that arm bore the brunt of pitched fighting. Cavalry and artillery were support arms. With the advent of rifled infantry weapons, it was no longer practical for artillery to be deployed along the front line of battle, as it had been up through the Mexican War. The exposed artillerymen were inviting and easy targets for enemy infantrymen armed with rifled muskets. During the Civil War, artillery had to adjust to a new role as long-distance support for the infantry or cavalry, a task that was facilitated in part by the application of rifling to cannons.
That change of role led to considerable fumbling and bumbling at first, but field commanders soon learned how to mass artillery for long-range use, as Union Maj. Gen. George B. McClellan did at Malvern Hill, as the Army of Northern Virginia did at Antietam--"artillery hell" in the words of Colonel Stephen D. Lee, a Confederate artillery battalion commander at that battle--and as Brig. Gen. Henry Hunt, a Federal artillery commander, did at Gettysburg, where he positioned each of his more than 300 artillery pieces so advantageously that every one was used during the battle.
Civil War artillery pieces came in a bewildering number of types. Those used in pitched battle were classified as field or light artillery, a designation meaning that the guns were light enough (a ton, more or less) to be hauled around by horses and manhandled when in action to provide tactical support for field armies in active campaigning. Light artillery stood in contrast to heavy artillery, the big guns seen in photographs of Civil War fortifications and places of permanent defense, such as the extensive works defending Washington, D.C., or seacoast fortifications.
Cannons were classified by the weight or caliber of the projectiles they fired. The smallest Civil War field artillery pieces fired 6-pound balls, and the largest fired 30-pound "bolts," or shells. The most common calibers and sizes were 2.9- or 3-inch (or 10-pound) shells and 12-pound round balls, but 20-pound bolts and 24-pound round balls were not uncommon.
The difference between round balls and bolts pointed to another basic way to differentiate Civil War artillery--smoothbores and rifles. Smoothbore cannons had been around since the dawn of gunnery. The insides of the barrels, the bores, were smooth and fired round iron balls, round explosive-filled case shot, or canister and grapeshot, without the advantage in range or accuracy provided by rifling. Yet smoothbore guns were surprisingly accurate. The famous 12-pounder Napoleon, the workhorse of Civil War artillery, could fire a round ball with reasonable accuracy up to 1,600 yards.
The advantages of rifling--the cutting of spiral grooves inside a gun bore to impart a spin to the projectile, thereby increasing range and accuracy--had been known for hundreds of years before the Civil War. Up to then, however, what prevented the widespread application of rifling was that virtually all cannons and small arms were muzzleloaders; that is, the ammunition had to be loaded by ramming it down the barrels from the front end of the guns. The projectiles had to be slightly smaller than the caliber of the bores to facilitate getting them down to the breech.
With smoothbore weapons, firing round, gently tumbling projectiles with reasonable range and accuracy, the difference in size was not too important. But for a rifled piece to work, the projectile had to fit tightly against the grooved bore. Until breechloading guns were perfected (as they were starting to be at the time of the Civil War, though most effectively in small arms), muzzleloading rifle projectiles had expandable bases. When fired, the projectile bases expanded to bite into the rifling, thereby giving a spin to the projectile. To further increase range and accuracy, an elongated projectile with a pointed front end was advantageous. In small arms, this was the famous lead Minie' bullet of the Civil War, and in rifled cannons it was an iron bolt with an expandable soft metal ring or base.
The difference in range and accuracy between a smoothbore and a rifled artillery piece was like the difference between throwing a basketball or a football. Whereas a smoothbore Napoleon had a range of 1,600 yards and could hit a barn at that range, a rifled 10-pounder Parrott gun could hit a barn door at up to 2,100 yards. While rifled cannons were ideal for long-range sniping, smoothbores, with their large bore sizes, were better at firing canister (a tin can filled with small iron balls) like a giant shotgun at massed troop formations in close quarters at 400 yards or less.
Many Civil War batteries were made up of a combination of rifles and smoothbores. The officers and gunners had to be conversant with the capabilities of each type of gun in their batteries. One Confederate-made Napoleon had a table of ranges crudely engraved into the cascabel (outside rear of the breech) for shot and shell. The table differed slightly from the standard table for Napoleons, which suggests that someone intimately familiar with that particular gun knew its idiosyncrasies well and wanted others using it to know, too.
One final distinction between Civil War cannons was the type of metal used for the barrels. Bronze was the ideal gun metal during the age of smoothbores. It was a very resilient medium that rarely if ever failed during use. It was, however, more expensive to cast a gun of bronze than one of iron, which was commonly used. When rifling came along, bronze had to be abandoned because it eroded under pressure and the rifling quickly wore out. Thus Civil War rifled guns were made either of cast iron or wrought iron. Wrought-iron guns, while less likely than those of cast-iron to fail or explode, were also tricky and more expensive to fabricate.
Whether smoothbore or rifled, bronze or iron, small- or large-caliber, every Civil War cannon had the same implements assigned to it for use in loading and firing. Two rammer staffs, used to pound home rounds and to sponge the bore after each firing, were secured to the underside of the gun carriage when not in use. A corkscrewlike device called a worm, for snagging and removing powder sack remnants after firing, and a water bucket to keep the sponge wet were also attached to the carriage's underside. Each gun carried two trail spikes that could be inserted into the rear of the gun's trail to serve as an aiming lever. Finally, neatly coiled on the top of a gun's trail was a heavy piece of rope, called the prolong, used in manhandling the gun.
In action a gun required, besides the gun corporal, seven cannoneers who performed specific functions with the implements to load and fire the gun. As casualties mounted, the manuals of the period provided protocols for operating the guns with reduced numbers, down to two men. Every man was trained to perform every function on the gun. There are even accounts of single individuals operating cannons during battle.
Each gun was hitched to the rear of a two-wheeled vehicle called a limber, upon which rode a limber chest with up to 50 rounds of ammunition. The limber was attached by means of a wooden limber pole to four or six horses arranged in pairs. Each left-hand horse had a rider, called a driver, who handled his horse and the one to its right. The horses required elaborate sets of leather tack (sometimes rope in the Confederate Army) and saddles for the drivers. Besides ammunition, the limber chest contained friction primers used to detonate each round, a detachable rear sight used by the gunners to aim, or point, the piece, and various implements to cut and attach slow-burning fuses used to detonate explosive shells when they arrived over their targets.
Various leather or canvas accouterments were also transported in the limbers. Pouches for primers, gunners' haversacks for conveying rounds from limber to gun, and thumbstalls (leather sheaths to protect a cannoneer's thumb while he sealed the cannon's vent during loading) would be found there. Also in the limber chest were lanyards (cords with handles and hooks used to set off friction primers), vent wires with which loaded rounds' flannel powder sacks were opened prior to firing, vent brushes, gimlets for clearing clogged vents, and locks for the chests.
In action, a limber was posted immediately to its gun's rear, so that ammunition and supplies were close at hand. Assigned to each gun and deployed farther to the rear during action would be another limber and limber chest. Hitched to this reserve limber was the caisson, which was also a two-wheeled vehicle. It carried two more limber chests of ammunition, plus a spare limber pole and a spare wheel. Limber-and-caisson combinations were also hauled by six-horse, three-driver teams. In battle, limbers and limber chests could be rotated from gun to caisson.
The battery wagon, which also had horses and drivers, served as a traveling pit stop for guns, limbers and caissons. It contained all sorts of extra parts and tools, such as shovels, axes and jacks, needed to maintain the other vehicles.
Watching a well-drilled artillery battery in action--cannoneers serving guns, drivers managing horses, limbers rotating to the rear for ammunition, artificers manning forges and making repairs, all under the watchful eye of the battery captain--must have been like watching a well-choreographed ballet. No wonder Frederick the Great thought that artillery lent dignity to what otherwise would have been a "vulgar brawl."

Article reprinted with the permission of:
America's Civil War
Copyright 2001
dba PRIMEDIA Enthusiast Publications

741 Miller Drive, SE, Suite D-2
Leesburg, VA  20175
Subscription # (800) 829-3340
Outside the US (904) 446-6914


The following article is reprinted with the permission of:
America's Civil War
Copyright 2001
dba PRIMEDIA Enthusiast Publications

741 Miller Drive, SE, Suite D-2
Leesburg, VA  20175
Subscription # (800) 829-3340
Outside the US (904) 446-6914



Horsepower Moves the Guns

Working side by side with soldiers,
horses labored to pull artillery pieces into battle.
Without them, field artillery could not have been
used to such deadly effect.

By James R. Cotner

The field artillery of the Civil War was designed to be mobile. When Union or Confederate troops marched across country, the guns moved with them. During battle, the guns were moved to assigned positions and then were switched from place to place, pulled back or sent forward as fortune demanded. The field batteries went galloping off to support an advance or repel an attack. When they withdrew, they contested the field as they went. Movement was everything. The guns could fulfill their essential function only when they could be moved where they were most needed.

At the time of the Civil War, such movement required draft animals--horses, mules or oxen. Mules were excellent at pulling heavy loads, but they were not used in pulling the guns and caissons of the field artillery. No animal liked to stand under fire. In the fury of battle, horses would shy and rear and flash their hooves; but mules carried their protests to the outer limits. When exposed to fire, mules would buck and kick and roll on the ground, entangling harnesses and becoming impossible to control.

An exception to the rule against using mules was their role in carrying small mountain howitzers. These guns were light enough to be broken down, with the component parts carried on the backs of pack animals. They had been developed for use in country that was mountainous and heavily wooded, with only trails or wretched roads. Strong, surefooted animals were needed, and mules were the obvious choice.

The danger of using mules in battle is vividly depicted in Confederate Brig. Gen. John D. Imboden's account of his seriocomic experience at the Battle of Port Republic in June 1862. In that engagement, Imboden, a colonel at the time, commanded a band of cavalry with a battery of mountain howitzers, carried on mules, in the army of Maj. Gen. Thomas "Stonewall" Jackson. At Port Republic, Jackson ordered Imboden to put his battery in a sheltered place and be ready, upon the enemy's withdrawal, to advance to a point where his guns would have a clear field of fire. Imboden took his men and the mules, carrying the guns and ammunition, into a shallow ravine about 100 yards behind Captain William Poague's Virginia battery, which was hotly engaged.

Within a few minutes, Union artillery shells were screaming across the ravine well above the sheltered men and mules. Imboden, in his account of the action, recalled: "The mules became frantic. They kicked, plunged and squealed. It was impossible to quiet them, and it took three or four men to hold one mule from breaking away. Each mule had about three hundred pounds weight on him, so securely fastened that the load could not be dislodged by any of his capers. Several of them lay down and tried to wallow their loads off. The men held these down and that suggested the idea of throwing them all to the ground and holding them there. The ravine sheltered us so we were in no danger from the shot or shell which passed over us."

The use of mules to carry mountain howitzers was a choice based on their fitness for the task, not due to any shortage of horses. The Manual for Mountain Artillery, adopted by the U.S. Army in 1851, stated that the mountain howitzer was "generally transported by mules." The superiority of mules in rough country outweighed their notorious contrariness under fire.

Plodding oxen obviously were not well suited for hauling field artillery, since rapid movement was often needed. Oxen were strong--their name is synonymous with strength and endurance--but they were too slow. Nevertheless, oxen were sometimes pressed into service during the Civil War.

In November 1863, Lt. Gen. James Longstreet's force was detached from the Confederate Army of Tennessee under General Braxton Bragg, then besieging Chattanooga. Longstreet's troops moved north through eastern Tennessee to confront Maj. Gen. Ambrose Burnside's Federal force at Knoxville. It was a long, harsh journey for the Confederate artillery. As the Southern army neared Knoxville, the Confederate caissons carrying ammunition for the field artillery were being pulled by oxen, a choice dictated by the scarcity of horses in the region.

All movement of field artillery was done with limbers. Guns, caissons, battery forges and wagons were all fastened to a lim-
ber. None, under ordinary circumstances, moved independent-
ly. A limber was an ammunition box mounted on an axle between two wheels, with a forward projecting pole, to which the team was hitched. Underneath and at the rear of the limber was a bent iron piece called the pintle. At the end of the gun trail or at the tip of a short pole on the caisson was an iron piece, pierced through, called the lunette. The gun trail was lifted and the hole in the lunette dropped over the pintle, making the piece and the limber a four-wheeled unit. The piece was joined to the limber at a pivot, giving the unit a short turning radius.

The capacity of a healthy horse to pull a load was affected by a number of factors. Chief among these was the nature of the surface over which the load was being hauled. A single horse could pull 3,000 pounds 20 to 23 miles a day over a hard-paved road. The weight dropped to 1,900 pounds over a macadamized road, and went down to 1,100 pounds over rough ground. The pulling ability was further reduced by one-half if a horse carried a rider on its back. Finally, as the number of horses in a team increased, the pulling capacity of each horse was further reduced. A horse in a team of six had only seven-ninths the pulling capacity it would have had in a team of two. The goal was that each horse's share of the load should be no more than 700 pounds. This was less than what a healthy horse, even carrying a rider and hitched into a team of six, could pull, but it furnished a safety factor that allowed for fatigue and losses.

John Gibbon finished the war as a major general in the Union Army. Before the war, he had served as an instructor at West Point and had written a textbook called The Artillerist's Manual that was used by cadets at the academy. In his textbook, Gibbon described what was desired in an artillery horse: "The horse for artillery service should be from fifteen to sixteen hands high....should stand erect on his legs, be strongly built, but free in his movements; his shoulders should be large enough to give support to the collar but not too heavy; his body full, but not too long; the sides well rounded; the limbs solid with rather strong shanks, and the feet in good condition. To these qualities he should unite, as much as possible, the qualities of the saddle horse; should trot and gallop easily, have even gaits and not be skittish."

Gibbon carefully described what was wanted, but horses with these qualities were not always available. Horses became scarce and stayed in short supply in areas of continuing conflict. Both North and South soon began to take horses that belonged to enemy sympathizers. This was often done not out of necessity but simply to deprive the enemy of horses.

In April 1862, Union Quartermaster General Montgomery C. Meigs was called upon to furnish a great number of horses for the Federal Army to use on the Virginia Peninsula. Meigs wrote to Secretary of War Edwin M. Stanton, telling him that there were horses for the taking from Southern sympathizers in the Shenandoah Valley and seeking authority to seize the animals. The authority was promptly given, with the stipulation that no horse needed for agricultural work was to be taken, even from an enemy sympathizer. In his request Meigs pointed out, "A horse for military service is as much a military supply as a barrel of gunpowder or a shotgun or rifle."

At the start of the war, the Northern states held approximately 3.4 million horses, while there were 1.7 million in the Confederate states. The border states of Missouri and Kentucky had an additional 800,000 horses. In addition, there were 100,000 mules in the North, 800,000 in the seceding states and 200,000 in Kentucky and Missouri. The disparity in the distribution of the mule population somewhat evened out the number of draft animals available for all purposes. The South furnished--involuntarily--many horses to the North. Most of the fighting was done on Southern soil, and the local horses were easily seized by Northern troops. While Confederates had opportunities to take Northern horses during Robert E. Lee's invasion of Pennsylvania and upon the occasional raids into Northern territory, the number taken was small compared to the thousands commandeered by Union troops, who occupied large areas of the South for several years.

In May 1863, the Federal brigade of Colonel John T. Wilder swept the country east and north of Murfreesboro, Tenn. Northern troops had been in the area for months, yet in five days the brigade took another 196 horses from the people of the region, despite attempts to hide the horses in woods, ravines and caves. One horse was found tied to a bedpost in a lady's back parlor.

Proper and adequate care of artillery horses was essential. If they were weakened by neglect, they could not long survive the rigors of active campaigning. Good commanders were aware of this and issued orders aimed at improving the animals' care.

On October 1, 1862, shortly after the Antietam campaign, Robert E. Lee issued Order No. 115, addressing the care to be given to all horses of the army and fixing responsibility upon specific officers for the care of the horses in the artillery reserve. Those guilty of neglect of battery horses were to be punished. No artillery horses were to be ridden except by designated artillerymen. The chief of artillery was empowered to arrest and bring to trial any man using a horse other than in battery service.

Union Maj. Gen. William T. Sherman, while still a divisional commander, issued a similar order to the artillery officers attached to his division. After outlining the many tasks to be performed when a battery came to a halt during a march, Sherman directed that "every opportunity at a halt during a march should be taken advantage of to cut grass, wheat, or oats and extraordinary care be taken of the horses upon which everything depends."

Feeding, of course, was a critical part of the horses' care. The daily ration prescribed for an artillery horse was 14 pounds of hay and 12 pounds of grain, usually oats, corn or barley. The amount of grain and hay needed by any particular battery depended on the number of horses that battery had at the time. It varied almost from day to day, but it was always enormous. The horses of the battery had to be fed each day, whether the battery moved or not. During the Civil War, an artillery battery might sit in the same place for weeks at a time, and yet consume thousands of pounds of hay and grain each day.

Artillery horses represented only a small number of the animals that had to be fed by the military. Besides the horses with the artillery, horses used by the cavalry, and horses and mules used to pull supply wagons and ambulances, there were also thousands of saddle horses carrying officers and couriers. Brigadier General Stewart Van Vliet, chief quartermaster of the Army of the Potomac during its campaign on the Virginia Peninsula in 1862, reported that 800,000 pounds of forage and grain were needed daily to feed the horses and mules. Since a wagon ordinarily carried 1 ton, the animals' daily food allowance required 400 wagonloads each day.

The prescribed rations were not always available. Sometimes, especially as the war went on and areas were picked clean by the opposing armies, severe shortages of grain and hay developed. At other times, there was available grain and hay but they could not be delivered to the batteries needing them. The artillery horses of the Union V Corps subsisted on a daily ration of five pounds of grain as Lt. Gen. Ulysses S. Grant pushed south in May 1864. The meager rations were the result of a shortage of wagons, not a lack of grain. After the artillery wagons had delivered hay and grain to the batteries, infantry units seized them and used them as makeshift ambulances to carry the thousands of wounded back from the Wilderness and Spotsylvania.

Pasturage was sometimes available, but green grass and field plants were not efficient foods. Eighty pounds of pasturage was needed to match the nutritional value of 26 pounds of dry hay and grain, the prescribed daily ration. In addition, green pasturage increased the likelihood that a horse might founder. Nevertheless, pasturage was used, either as a supplement to the regular ration or as the primary source of nutrition for short periods, if hay and grain were not available.

In January 1865, the men in Kirkpatrick's Battery, serving with the Confederate army of Lt. Gen. Jubal A. Early in the Shenandoah Valley, were granted "horse furloughs." A hot, dry summer had greatly reduced the crops in the area, and there was little food for the men and none for the horses. To meet this crisis, artillerymen whose homes were nearby were allowed to return home if each took a horse with him. The furloughed soldier was expected to feed and care for the horse; when spring arrived, he was to return to the battery with the horse. Admittedly, this was a risky business considering the Confederacy's situation that January. Apparently, it was worth the risk of losing a veteran to save a horse.

Water for the horses was a problem that demanded an adequate solution every day. While in camp, a battery would discover the nearest creek or pond and routinely water the horses there. On the march, water had to be found at the end of each day. If the water was any distance, as it often was, the timing of the watering was critical. The guns were immobile if the horses were absent. Usually, only half the horses would be sent to water at any one time. This meant that in an emergency some movement might be achieved, but with only half the horses present, the battery was at a distinct disadvantage.

At the Battle of Stones River in December 1862, Battery E of the 1st Ohio Artillery was stationed on the right of the Union line, facing the mist-filled cedar thickets out of which the Confederates would come screaming at dawn. Just before the attack began, half the battery horses were taken to a small stream some 500 yards to the rear. In the debacle that followed the initial attack, all the battery guns were lost. Some accounts of the battle mention the absence of the horses and hint that it was a factor in the loss of the guns. The battery did fight valiantly where it stood, pouring canister fire into the advancing Rebels, until the entire Union brigade was smashed and sent careening back. Troops assigned to support the battery abandoned it. It is difficult to believe that the outcome would have been different even if all the horses had been present.

Another incident where the watering of artillery horses caused a delay and perhaps thwarted an attack occurred at Petersburg, Va., on June 15, 1864. Brigadier General William F. "Baldy" Smith and the Federal XVIII Corps stood before the city, then defended by only 2,200 men, many of whom were untried militia with little if any fighting experience. The intended Federal assault was delayed for more than an hour when it was discovered that the artillery horses had all been unhitched and taken to water. The attack did not begin until 7 p.m., when it was beaten back. Some accounts blame the failure on the absent artillery horses. Veteran reinforcements arrived to bolster the defense just as the Confederate lines broke. Some have speculated that without the delay Petersburg might have been taken nine full months before it finally fell.

In spite of the care given to artillery horses, the animals still perished at an astounding rate. Many died of disease or were put to death because of exhaustion. Many more were killed alongside their battery mates in battle.

When a battery unlimbered and took its place in line, the horses were ordinarily moved to a place sheltered from direct enemy fire--behind a building or hill, in a copse of trees or in a ravine. Such precautions, however, did not always protect the animals from hostile fire.

On the third day at Gettysburg in July 1863, many of the Union artillery horses were placed on the eastern slope of Cemetery Ridge, behind and below the crest. In the great barrage that preceded Pickett's Charge, the position inadvertently became a death trap. Brigadier General Henry J. Hunt, chief of artillery for the Federal forces, reported that fire from the Confederate guns was high. It passed over the crest and exploded or fell among the horses on the eastern slope. As Hunt reported, "This cost us a great many horses and the explosion of an unusually large number of caissons and limbers." The Union artillery lost 881 horses at Gettysburg. All of those animals were not killed on the eastern slope of Cemetery Ridge, but it may be assumed from Hunt's remarks that many were.

Horses suffered not only from artillery fire but also from the fire of advancing infantry. The capture of a piece of artillery was a great exploit, bringing with it honor and recognition. Confederate regiments in the Western theater were allowed to place crossed cannons on their regimental battle flags after they had taken a Federal gun.

One tactic used in attacking a battery was to shoot down the horses attached to it. If the battery horses were killed or disabled, moving the guns back to safety was an impossible task. But horses could take much punishment. They were difficult to bring down, and once down were difficult to keep down, even with the impact of the large-caliber Minie bullets.

At Ream's Station in August 1864, the 10th Massachusetts Battery fought from behind a low makeshift barricade, with its horses fully exposed only a few yards behind the guns. The battery was fighting with five guns, and in a short time the five teams of six horses came under fire. Within minutes only two of the 30 animals were still standing, and these all bore wounds. One horse was shot seven times before it went down. Other horses were hit, went down, and struggled back up, only to be hit again. The average number of wounds suffered by each horse was five. The Confederates were firing from a cornfield approximately 300 yards away.

By far the greatest number of horses were lost to disease and exhaustion. Again referring to the 10th Massachusetts Battery, reports reveal a dismal trail of horses dying from disease or being put to death because of exhaustion. Between October 18, 1862, when its service began, and April 9, 1865, when Lee surrendered, the battery lost a total of 157 horses from causes other than combat. Of these, 112 died from disease. The most prevalent disease in the battery was glanders, which claimed 45 horses. Glanders, a highly contagious disease that affects the skin, nasal passages and respiratory tract of horses and mules, was also called farcy or nasal gleet in wartime reports.

Forty-five of the battery's horses were lost to fatigue when they simply became worn out and unable to work, and so were put to death. The losses to exhaustion can be keyed to specific events. In June 1864, 13 battery horses were lost to exhaustion, reflecting the crushing pace of Grant's advance after leaving the Wilderness. In the days after the fall of Richmond, 14 horses went down as a result of the hard pursuit of Lee's retreating army. Even when the surrender came, the killing chase continued to take its toll, with an additional 22 horses being put to death due to exhaustion between April 10 and April 15.

The horses were worked hard and long, but it had to be so. A battery racing to catch up with a retreating enemy or to gain a position of advantage had no room for gentle treatment. The stakes were high, and the horses paid the price. The alternative might be defeat. A man on a long, hot march, pushed beyond what his body could bear, might drop out temporarily and catch up with his company later. Horses had no such choice. Harnessed to the limbers, they pulled until they fell or, as happened in most instances, until they harmed their bodies beyond healing, and then were shot.

Mud or dust seemed to plague every movement of troops. Of the two, mud was the greater problem for the artillery. Dust created great discomfort, but little more. While an artilleryman might find it difficult to breathe and intolerably itchy in the suffocating dust, the guns and caissons could still be moved. Mud, on the other hand, often made movement impossible. Sinking below their axles in holes full of clinging muck, guns and caissons could be moved only with superhuman effort, the men pushing at the wheels and extra horses pulling on the traces. Sometimes guns were simply abandoned to the mud.

A battery moved at the same speed and covered the same distance as did the troops to which it was attached. This distance could be anywhere from a few miles to 20 or 30 miles a day. When a battery moved independently, it was not limited by the movement of the troops and was thus free to cover as much ground as it could. All in all, there was not a great deal of difference in the distance traveled. Such gains as there were resulted from the absence of thousands of marching infantrymen, supply trains and other units cluttering up the roads. The battery was then able to travel without long delays due to the inevitable traffic jams caused by jostling troops.

Five days were needed for Knap's Pennsylvania Battery to travel from Leesburg, Va., to Littletown, Pa., a distance of 80 miles. The battery marched with the XII Corps. The longest distance traveled in one day was 21 miles, while the shortest was 12. The same battery, when it was unattached and moving independently in September 1863, covered the 59 miles from Brandy Station to Alexandria in only 11Ž2 days, traveling 37 miles the first day and 22 the second.

Brigadier General E.P. Alexander, chief of artillery in Lt. Gen. James P. Longstreet's Confederate corps, reported that on July 3, 1863, the reserve artillery of Lee's army, consisting of 89 guns, moved from Greenwood, Pa., to a point one mile west of Gettysburg in only six hours. The march of 17 miles began at 1 a.m. and was completed by 7 a.m.

One way or another, at Gettysburg and dozens of other Civil War battles, the humble horse and his human masters soldiered on. Whether plodding through the dry, stifling dust, struggling in clinging mud, rushing up to a position at a jolting gallop or creeping backward in a fighting withdrawal, the men--and the horses--always did what had to be done. They moved the guns.

Article reprinted with the permission of:
America's Civil War
Copyright 2001
dba PRIMEDIA Enthusiast Publications

741 Miller Drive, SE, Suite D-2
Leesburg, VA  20175
Subscription # (800) 829-3340
Outside the US (904) 446-6914


Summer 2001
